This is a 4 channel analog mixer meant for mixing audio signals.
You can use this to MIX CV signals, but since this mixer uses 1.65V as the virtual ground, the end result will be different.
Functionality
This can be used as a final mixer or as a submix. This module uses rail-to-rail opamps. So, even though we work with a 3.3V setup, it has capable headroom.
Additional Parts
This section is only relevant if you are buying the semi-assembled module. You have to source & solder the following parts. You can check our guide on common parts for where to source these components.
- 2.54mm Header Pins (5-pin) - 2
- Circular Pin Header Sockets (5-pin) - 2
- 50K Potentiometers - 4
